Greenline Pipe and Fitting is the most trustable and widest manufacturer and supplier of the SS 316, 316L, 316H Pipe and Tubes We also manufacture all other SS 316 grade tubes and pipes. We provide our product in both the national and international markets. SS 316 is the most authentic stainless steel and is the standard molybdenum-bearing grade also.
SS 316L Pipe has excellent characteristics of welding and forming. It also has excellent corrosion to tartaric acids, formic, acetic, hydrochloric, and sulfuric acids. SS 316H Pipe has excellent mechanical properties like outstanding thermal conductivity, tensile strength, electrical resistivity, and thermal expansion.
The properties of Austenitic Stainless Steel 316, 316L, 316H Pipe, Tube are that when it is used in temperatures ranging from 425 degrees Celsius to 860 degrees it is resistant to carbide precipitation. And it can be utilized in the harsh marine conditions and also used in marine sector. SS 316L Tube at elevated temperatures offers high tensile strength, stress to rupture and high creep strength. These grade tubes are mostly suited for formed and fabricated applications like pharmaceutical processing, pulp, and paper processing equipment, fasteners, surgical tools, and refining equipment.
The properties of SS 316H Tube are it is anti-corrosive, good machine-ability, weldability and formability, good dimensional accuracy, pitting/crevice corrosion, and stress corrosion cracking resistance, and also has high tensile strength. The chemical composition of SS 316 Tube contains silicon 0.75; Nickel 10.0min-14.0 max, Sulfur- 0.03, Manganese 2.00, Carbon 0.08, Nitrogen 0.1, Chromium 16.0 min -18.0 max, Phosphorus 0.045, and molybdenum 2.00 min -3.00max.
SS 316, 316L, 316H pipe and tubing specification is ASTM A/ASME SA213/ A249/A269/ A312/ A358 CL. I to V ASTM A789/A790 and the dimensions are ASTM/ASME/API; it comes in round, hydraulic, rectangular, and square form. The end is particularly threaded, beveled end/ and single random. The type of this pipe and tube is seamless, LSAW, fabricated, welded, and ERW.
The entire product goes through various tests to check and maintain the quality of the product globally. The test is a hardness test, micro/mini test, radiography test, mechanical test, chemical test, PMI test, intergranular test, etc. Proper packaging is also done to protect the material form any kind of loss.
Specifications : ASTM A213, A249, A269, A312, A358 / ASME SA213, SA249, SA269, SA312, SA358
Standard : ASTM, ASME and API
Dimension Standard : ANSI B36.19M, ANSI B36.10
Seamless Pipe Size : 1/2″ NB – 16″ NB
ERW Pipes Size : 1/2″ NB – 24″ NB
EFW Pipes Size : 6″ NB – 100″ NB
Pipes Outside Diameter : 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available
Seamless Tubes Size : 1/2" OD - 12" OD
Welded Tubes Size : 1/2" OD - 12" OD, Guage: 25 SWG - 10 SWG
Tubes Outside Diameter : 3.00 mm - 219.10 mm, 6.35 mm O.D to 114.3 mm O.D
Pipe Thickness : 0.3mm – 50 mm
Tubes Thickness : 0.40 mm - 12.70 mm, 0.8 mm to12.7 mm
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH120, SCH140, SCH160, XXS
Type : Seamless, Welded, ERW, EFW
Form : Round Pipes, Square Pipes, Rectangular Pipes
End : Plain End, Beveled End, Treaded
|SS 316||1.4401 / 1.4436||S31600||SUS 316||316S31 / 316S33||-||Z7CND17-11-02||X5CrNiMo17-12-2 / X3CrNiMo17-13-3|
|SS 316L||1.4404 / 1.4435||S31603||SUS 316L||316S11 / 316S13||03Ch17N14M3 / 03Ch17N14M2||Z3CND17-11-02 / Z3CND18‐14‐03||X2CrNiMo17-12-2 / X2CrNiMo18-14-3|
|SS 316H||1.4401||S31609||SUS 316L||-||-||-||-|
|SS 316||0.08 max||2.0 max||1.0 max||0.045 max||0.030 max||16.00 - 18.00||2.00 - 3.00||11.00 - 14.00||67.845 min|
|SS 316L||0.035 max||2.0 max||1.0 max||0.045 max||0.030 max||16.00 - 18.00||2.00 - 3.00||10.00 - 14.00||68.89 min|
|SS 316H||0.10 max||2.0 max||0.75 max||0.045 max||0.030 max||16.00 - 18.00||2.00 - 3.00||10.00 - 14.00||68.89 min|
|Density||Melting Point||Tensile Strength||Yield Strength (0.2%Offset)||Elongation|
|8.0 g/cm3||1400 °C (2550 °F)||Psi – 75000 , MPa – 515||Psi – 30000 , MPa – 205||35 %|
